CCEC KTA19 Marine Main Engines Detailed information

The CCEC K19-M series marine main engine is a robust and versatile engine designed for marine applications. Below is a summary of its key features and configurations:
Key Specifications:
Cylinder Configuration: 6-cylinders in line
Displacement: 19 liters
Bore and Stroke: 159 mm (6.25 in) x 159 mm (6.25 in)
Engine Type: Four-stroke
Fuel System: PT Fuel System
Turbocharger: Equipped with a turbocharger
Power Range: 425 HP to 700 HP (317 kW to 522 kW)
Torque Range: 1851 N.m to 2830 N.m
Configurations:
The CCEC K19-M series offers different configurations based on turbocharging and cooling methods, indicated by codes in the engine model name:
T: Turbocharged engine
TA: Turbocharged with water-air intercooler
TAA: Turbocharged with air-air intercooler
Cooling Options:
Heat Exchanger Cooling: Standard cooling system using a heat exchanger.
Keel Cooling: Alternative cooling system suitable for specific marine applications.
Services Provided:
CCEC offers comprehensive support throughout the engine’s lifecycle, including:
Design and Power System Supply
Installation and Commissioning
After-Sales Service Training
Spare Parts Supply
Troubleshooting and Overhaul Technical Support
Applications:
The CCEC K19-M series is suitable for a wide range of marine vessels, providing reliable power and performance for various operational requirements.
This engine series is designed to deliver high performance, durability, and efficiency, making it a strong choice for marine propulsion and auxiliary power needs.
